OPPAIR Energy saving screw air compressor Customizable PM VSD Compressors
Next:
Permanent magnet frequency conversion energy-saving 7.5kw 11kw 15kw 22kw 30kw 37kw 8bar screw air compressor
7.5kw 11kw 15kw 22kw 30kw 37kw 0.8-6.8m3/min permanent magnet integrated screw air compressor
¥5,700.00
1.Level 1 energy efficiency
2.Permanent magnet variable frequency motor
3.Home delivery
4.National warranty after-sales worry
5.Strong and durable
Factory area: 3100m3, annual output: 6000+ units, exported to 30+ countries
Features: LCD display intelligent chip inverter motor power protection energy saving low noiseGood heat dissipation, not easy to high temperature, Large gas, wear resistance, corrosion resistance, power saving is the hard truth
| Smart Serial parameter | ||||||
| Model number | Smart-10 | Smart-15 | Smart-20 | Smart-30 | Smart-40 | Smart-50 |
| power(kw) | 7.5 | 11 | 15 | 22 | 30 | 37 |
| horse-power(hp) | 10 | 15 | 20 | 30 | 40 | 50 |
|
Exhaust volume /Working pressure (m³/min. / bar) |
1.2 / 7 | 1.6 / 7 | 2.5 / 7 | 3.8 / 7 | 5.3 / 7 | 6.8 / 7 |
| 1.1 / 8 | 1.5 / 8 | 2.3 / 8 | 3.6 / 8 | 5.0 / 8 | 6.2 / 8 | |
| 0.9 / 10 | 1.3 / 10 | 2.1 / 10 | 3.2 / 10 | 4.5 / 10 | 5.6 / 10 | |
| 0.8 / 12 | 1.1 / 12 | 1.9 / 12 | 2.7 / 12 | 4.0 / 12 | 5.0 / 12 | |
| Air outlet size | DN15 | DN20 | DN20 | DN25 | DN40 | DN40 |
| Lubricating oil quantity (L) | 6 | 10 | 10 | 15 | 22 | 22 |
| noise dB(A) | 60±2 | 62±2 | 62±2 | 64±2 | 66±2 | 66±2 |
| Connection mode | Direct connection | |||||
| type | Permanent magnet frequency conversion | |||||
| Starting mode | Variable frequency starting | |||||
| Length(mm) | 780 | 1000 | 1000 | 1070 | 1200 | 1200 |
| width (mm) | 600 | 700 | 700 | 800 | 950 | 950 |
| height(mm) | 870 | 1070 | 1070 | 1150 | 1250 | 1250 |
| weight (kg) | 175 | 220 | 240 | 390 | 420 | 430 |
